- SRM50-HSA0-S21
| Performance | |
|---|---|
| Type of code for the absolute value | Binary |
| Code sequence | Increasing, when turning the shaft For clockwise rotation, looking in direction “A” (see dimensional drawing), For clockwise shaft rotation, looking in direction “A” (see dimensional drawing) |
| Communication interface | HIPERFACE® |
| Electrical data | |
| Connection type | Male connector, 8-pin, radial |
| Recommended supply voltage | 8 V DC |
| Power consumption | 80 mA |
| Output frequency for sine/cosine signals | ≤ 200 kHz |
| MTTF: mean time to dangerous failure | 235 years (EN ISO 13849) |
| Mechanical data | |
| Shaft version | Tapered shaft |
| Flange type / stator coupling | Spring mounting plate, Spring mounting plate |
| Dimensions | See dimensional drawing |
| Moment of inertia of the rotor | 10 gcm² |
| Operating speed | ≤ 12,000 min⁻¹ |
| Angular acceleration | ≤ 200,000 rad/s² |
| Operating torque | 0.2 Ncm |
| Start up torque | + 0.4 Ncm |
| Permissible movement of the drive element, static | ± 0.3 mm radial / ± 0.75 mm axial |
| Permissible movement of the drive element, dynamic | ± 0.1 mm radial / ± 0.2 mm axial |
| Angular motion perpendicular to the rotational axis, static | ± 0.005 mm/mm |
| Angular motion perpendicular to the rotational axis, dynamic | ± 0.0025 mm/mm |
| Life of ball bearings | 3.6 x 109 revolutions |
| Ambient data | |
| Operating temperature range | –20 °C ... +115 °C |
| Storage temperature range | –40 °C ... +125 °C, without package |
| Relative humidity/condensation | 90 %, Condensation not permitted |
| Resistance to shocks | 100 g, 10 ms, 10 ms (according to EN 60068-2-27) |
| Frequency range of resistance to vibrations | 20 g, 10 Hz ... 2,000 Hz (EN 60068-2-6) |
| EMC | According to EN 61000-6-2 and EN 61000-6-3 |
| Enclosure rating | IP40, with mating connector inserted (IEC 60529) |
| Classifications | |
| eCl@ss 5.0 | 27270590 |
| eCl@ss 5.1.4 | 27270590 |
| eCl@ss 6.0 | 27270590 |
| eCl@ss 6.2 | 27270590 |
| eCl@ss 7.0 | 27270590 |
| eCl@ss 8.0 | 27270590 |
| eCl@ss 8.1 | 27270590 |
| eCl@ss 9.0 | 27270590 |
| eCl@ss 10.0 | 27273805 |
| eCl@ss 11.0 | 27273901 |
| eCl@ss 12.0 | 27273901 |
| ETIM 5.0 | EC001486 |
| ETIM 6.0 | EC001486 |
| ETIM 7.0 | EC001486 |
| ETIM 8.0 | EC001486 |
| UNSPSC 16.0901 | 41112113 |
| Základné informácie | |
| Supply voltage | 7 V DC ... 12 V DC |
| Tags | |
|---|---|
| Tags |
HIPERFACE
SRS/SRM50
SICK
Motor feedback systems rotary HIPERFACE®
HIPERFACE®
|
